Cummins Onan SD 7500 Diesel Commercial Mobile Generator - 7.5HDKAL-1, 7.5 kW Prime, Single-Phase, 120/240 Volt, Liquid-Cooled
The Cummins Onan Hydraulic Series of generators are designed as a fully-integrated power system that includes the hydraulic pump, motor generator, filtration system, oil cooler and reservoir in one complete, compact, and lightweight package. This unit gives you great installation flexibility with remountable 90° exhaust elbow, remountable DC control and multiple oil fill/check points. Cummins Onan Hydraulic generators start under full load and run at the rated output, giving you all the power and performance you’re paying for. Cummins backs this generator with a standard 2 year limited warranty.
Features
| Manufacturer | Cummins |
|---|---|
| SKU | 7.5HDKAL-1 |
| Model Number | SD 7500 |
| Alternate Model Number | A061A428 |
| Generator Grade | Commercial |
| Generator Style | Commercial Mobile Generator |
| Engine/Motor Brand | Kubota |
|---|---|
| Engine Model | D1105 |
| Fuel Type | Diesel |
| Starting System | Electric |
| Horsepower | 17.1 HP |
| Engine/Motor Type | 3-Cylinder, Vertical, Liquid-Cooled, In-Line |
| Displacement | 1124 cc |
| Engine RPM | 1800 RPM |
| Generator RPM | 1800 RPM |
| Fuel Tank | Add @ Checkout |
| Fuel Cons. @ 50% Ld | 0.6 |
| Fuel Cons. @ 100% Ld | 0.9 |
| Fuel Induction System | Electronic Fuel Injection |
| Engine Governor | Electronic |
| Operational Volume (dB @10ft) | 76.0 |
| Operational Volume (dB @50ft) | 63.0 |
| Muffler/Exhaust | Enclosed Spark-Arrestor |
| Altitude Affected | Yes, Call For More Information |
| Remote Panel | Add At Checkout |
|---|---|
| Wire Harness | Add At Checkout |
| Vibration Isolators | Yes |
| Battery For Electric Start | Not Included |
| Warranty | 2 Year (Limited) |
|---|
| Weight (Lbs.) | 490 |
|---|---|
| Ship Weight (Lbs.) | 530 |
| Operating Weight (Lbs.) | 490 |
| Free Shipping | Yes |
| Dimension No Wheel Kit | 21"W x 37.3"L x 23.9"H |
| Agency Compliance | CARB (California), EPA Tier 4 Final, National Park Approved |
| QSP | 4-10wk |
| Stk. Itm. | No |
| Surge Start Watts | 7,500.0 |
|---|---|
| Continuous Rated Watts | 7,500.0 |
| Prime Rating Watts | 7,500 |
| Phase | Single-Phase |
| Voltage | 120, 240 |
| Rated Amps @ Min Volt (Commonly 120v) | 62.5 |
| Rated Amps @ Max Volt (Commonly 240v 1-Phase) | 31.3 |
| Frequency | 60 Hz |
| Power Factor | 1.0 |
| Poles | 2 |
| Alternator | Inverter |
| Voltage Regulation | Auto Voltage Regulation |
| Voltage Regulation Type | Digital |
| Frequency Regulation | +/- 1.0% |
| Circuit Breakers | 35 Amp |
| Insulation | Class H |
